DAHUA DH-IPC-PTS2649C-3E3Z-4GB20 Solar Battery Camera | Dual Lens 3+3MP | 4G SIM Card | WizColor | AOV | Construction Site CCTV Singapore

The DAHUA DH-IPC-PTS2649C-3E3Z-4GB20 is a professional dual-lens 4G solar-powered PT network camera designed for remote locations, construction sites, temporary works, infrastructure projects and outdoor areas where fixed power and wired Internet are unavailable.

A specification correction is important for accurate SEO: this model is 3MP + 3MP dual lens, not 4MP, and Dahua officially rates it IP66, not IP67. It combines a fixed overview camera with a motorised PT camera, 6× hybrid zoom, AOV Always-On Video, WizColor, 4G connectivity, 65Wh battery, 8W solar panel, SMD 3.0, Auto Tracking Lite, two-way audio and up to 512GB microSD storage. (Dahua Technology)

Key Specifications

Dahua's official specification confirms these capabilities. (Dahua Technology)

Dual Lens — One Camera, Two Views

One of the strongest features of the DH-IPC-PTS2649C-3E3Z-4GB20 is its dual-camera architecture.

Instead of relying on one lens, the unit combines:

3MP Fixed Lens → Overall Scene Monitoring

3MP PT Lens → Pan/Tilt Target Monitoring

The fixed camera maintains the broader overview while the PT camera can follow activity and provide a closer view. Dahua describes the coordinated fixed/PT monitoring design as providing a 360° view without blind spots. (Dahua Technology)

This architecture is particularly attractive for large outdoor areas.

6× Hybrid Zoom

The camera provides 6× hybrid zoom, allowing the system to obtain a closer view of distant activity without requiring a conventional large PTZ camera. (Dahua Technology)

For example:

Fixed Camera Detects Activity

↓

PT Camera Moves Toward Target

↓

Hybrid Zoom Provides Closer View

↓

Tracking Continues

This is useful for temporary construction sites, remote compounds, equipment yards and open areas.

Auto Tracking Lite

The DH-IPC-PTS2649C-3E3Z-4GB20 supports:

Auto Tracking Lite + Linkage Tracking

along with human and vehicle detection. (Dahua Technology)

This allows the PT lens to react to relevant activity detected within the surveillance scene.

Rather than requiring an operator to manually move the camera continuously, the intelligent functions can help automate target monitoring.

DAHUA DH-IPC-PTS2649C-3E3Z-4GB20 Solar Battery Camera | Dual Lens 3+3MP | 4G SIM Card | WizColor | AOV | Construction Site CCTV Singapore

AOV — Always-On Video

Another major feature is Dahua AOV Mode – Always-On Video.

Dahua specifically states that AOV enables 24/7 recording with ultra-low power consumption. (Dahua Technology)

This is particularly significant for a battery-powered camera.

In AOV mode, Dahua specifies approximately 170mW consumption when recording one frame every two seconds to the SD card while maintaining the 4G connection. (Dahua Technology)

This provides a different operating concept from ordinary battery cameras that simply sleep until motion wakes them.

WizColor — Low-Light Colour Imaging

Both camera channels use F1.0 optics, with Dahua specifying minimum colour illumination down to 0.0005 lux under its stated test conditions. (Dahua Technology)

Dahua's WizColor technology is intended to deliver useful colour imagery in extremely low-light conditions.

For construction sites and remote facilities, colour information can be particularly valuable when identifying:

Clothing • Vehicles • Machinery • Equipment • Objects

during nighttime incidents.

4G SIM Card Connectivity

The camera incorporates 4G cellular connectivity, removing the requirement for a fixed broadband connection at the installation location.

A typical architecture is:

DAHUA Solar Camera

↓

4G SIM Card / Mobile Network

↓

Internet

↓

DMSS Mobile App

This makes the camera particularly useful where there is:

No Fibre + No LAN + No Wi-Fi + No Fixed Internet

The EAU/EUR version supports multiple LTE-FDD and LTE-TDD bands, but the exact regional variant and local operator compatibility should be checked before deployment. (Dahua Technology)

Solar Panel + 65Wh Battery

The camera contains a:

65Wh Built-in Lithium Battery

and comes with an:

8W Solar Panel

It can additionally be charged through USB Type-C with QC2.0 support. (Dahua Technology)

The basic power architecture is:

SUNLIGHT

↓

8W SOLAR PANEL

↓

65Wh BATTERY

↓

DUAL-LENS 4G CAMERA

This eliminates the need to install conventional AC power at many temporary or remote locations.

Actual autonomy depends on sunlight, operating mode, 4G signal quality, tracking frequency, illumination usage, temperature and battery condition.

DAHUA DH-IPC-PTS2649C-3E3Z-4GB20 Solar Battery Camera | Dual Lens 3+3MP | 4G SIM Card | WizColor | AOV | Construction Site CCTV Singapore

Up to 512GB Local Storage

The camera supports:

microSD Card up to 512GB

for local recording. (Dahua Technology)

This is especially valuable for 4G CCTV because continuously uploading every second of video through a cellular network can consume substantial mobile data.

A more efficient architecture can be:

Local SD Recording

4G Alarm Notification

Remote Live View When Required

This reduces unnecessary SIM-card data usage.

Active Deterrence

The camera provides both:

White-Light Warning

and

Audible Warning

Dahua specifies three available alarm sounds, with configurable volume and playback repetitions. (Dahua Technology)

This creates a useful security sequence:

DETECT → TRACK → RECORD → ALERT → DETER

For unmanned construction sites and remote facilities, active deterrence can be particularly valuable.

Two-Way Audio

The camera has a:

Built-in Microphone

Built-in Speaker

supporting two-way communication. (Dahua Technology)

An authorised remote operator can therefore potentially view activity and communicate with a person at the site.

This is useful for security warnings such as unauthorised entry into a restricted work area.

DMSS Mobile App

Dahua officially lists DMSS as the management software/mobile client for Android and iOS. (Dahua Technology)

This provides a convenient architecture for remote monitoring:

Construction Site

↓

Solar 4G Camera

↓

Mobile Network

↓

DMSS

↓

Security / Project Management

The actual remote functions available depend on the camera configuration, network connectivity and user permissions.

SmartPSS Compatibility — Check Before Specifying

For this particular model, Dahua's current official specification lists DMSS as the management software. It does not list SmartPSS on the current product specification. (Dahua Technology)

Therefore, I would avoid advertising:

“SmartPSS Supported”

unless the exact firmware/version has been tested successfully.

For professional projects requiring centralised PC/VMS management, confirm software compatibility before tender submission.

Singapore MOM Construction-Site VSS Requirements

This camera is potentially interesting for Singapore construction-site monitoring, but “MOM compliant” should not be claimed based on the camera model alone.

Since 1 June 2024, Singapore MOM requires construction worksites with a contract value of S$5 million and above to install Video Surveillance Systems (VSS). (Ministry of Manpower)

MOM states that the VSS must be capable of:

Minimum HD 1080 resolution

At least 12 frames per second

Export to AVI, MP4 or another common multimedia format

Date stamp

Time stamp

Camera identification code

and recordings must generally be retained for at least 30 days, or 180 days after a reportable WSH incident. (Ministry of Manpower)

The Dahua camera itself provides 3MP at 15fps, exceeding MOM's basic resolution and frame-rate thresholds. (Dahua Technology)

However, compliance applies to the complete VSS deployment, including placement, recording, retention and export—not merely the camera specification.

“Suitable for MOM VSS Construction-Site Applications, subject to complete system design and compliance requirements.”

This is more accurate than claiming the camera itself is “MOM Certified.”

Singapore MOM – Video Surveillance System Requirements for Construction Sector

Where MOM Requires VSS Coverage

For applicable construction worksites, MOM specifies VSS coverage at areas involving activities such as work at height above 2m, scaffolding/formwork, excavation and shoring, lifting operations, industrial trucks, hazardous vehicular traffic, loading/unloading and certain confined-space work. (Ministry of Manpower)

A solar/4G camera can be particularly useful where these work zones move as construction progresses.

Instead of repeatedly installing:

AC Power + CAT6 + Network Switch + Fibre

the camera can potentially be relocated with the changing work area.

Workplace Privacy & CCTV

MOM also notes that workplace surveillance involving personal data must comply with applicable PDPA obligations. Organisations should establish clear rules, use surveillance at appropriate safety/security locations, inform workers of the purpose, and implement safeguards around storage and use of recordings. (Ministry of Manpower)

Therefore, construction-site CCTV should be deployed as part of a documented WSH, security and data-management policy.

Ideal Applications

The DH-IPC-PTS2649C-3E3Z-4GB20 is particularly suitable for:

Construction Sites • Temporary Worksites • Roadworks • Excavation Areas • Equipment Yards • Remote Compounds • Farms • Vacant Land • Car Parks • Infrastructure Projects • Outdoor Events • Temporary Security Deployments

Its strongest value proposition is:

NO AC POWER + NO LAN + NO WI-FI = SOLAR + BATTERY + 4G CCTV

DAHUA DH-IPC-PTS2649C-3E3Z-4GB20 Solar Battery Camera | Dual Lens 3+3MP | 4G SIM Card | WizColor | AOV | Construction Site CCTV Singapore

SGCCTV DAHUA Solar 4G CCTV Singapore

SGCCTV – Choicecycle CCTV Pte Ltd provides DAHUA Solar CCTV, 4G SIM Card Cameras, Construction Site CCTV, Mobile CCTV, Battery Cameras, Temporary CCTV, MOM VSS solutions, CCTV rental, CCTV sales, installation and troubleshooting.

Website: www.sgcctv.com.sg
Email: enquiry@choicecycle.com.sg
WhatsApp: +65 9853 4404

10 Frequently Asked Questions

1. Is DH-IPC-PTS2649C-3E3Z-4GB20 a dual-lens camera?
Yes. It combines a 3MP fixed camera and a 3MP PT camera, allowing coordinated overview and movable target monitoring. (Dahua Technology)

2. Is this a 4MP camera?
No. The official specification is 3MP + 3MP, with each channel supporting up to 2304 × 1296 resolution. (Dahua Technology)

3. Does it support 4G SIM connectivity?
Yes. The camera has integrated 4G cellular connectivity. Select the appropriate regional version for the intended mobile network. (Dahua Technology)

4. Does it need AC power?
Not necessarily. It has a 65Wh built-in battery and comes with an 8W solar panel. USB Type-C charging is also supported. (Dahua Technology)

5. Does it support 24/7 recording?
It supports Dahua AOV Always-On Video, designed for 24/7 recording with ultra-low power consumption. (Dahua Technology)

6. Does it have auto tracking?
Yes. Dahua specifies Auto Tracking Lite and linkage tracking, together with human and vehicle detection. (Dahua Technology)

7. How much SD storage does it support?
The camera supports a microSD card up to 512GB. (Dahua Technology)

8. Is it IP67?
No. Dahua's official specification lists IP66 protection, plus TVS 2000V lightning, surge and voltage-transient protection. (Dahua Technology)

9. Is this camera MOM compliant?
The camera's 3MP/15fps capability exceeds MOM's minimum 1080p/12fps VSS thresholds, but MOM compliance concerns the complete surveillance system—including coverage, timestamps, export capability and recording retention. It is therefore better described as potentially suitable for a compliant VSS design rather than as an independently “MOM-certified camera.” (Dahua Technology)

10. Can SGCCTV provide construction-site solar CCTV?
Yes. SGCCTV Choicecycle provides solar-powered, battery and 4G CCTV solutions for temporary and remote-site surveillance, including system design, installation and troubleshooting.
